If the Con trol pa nel has sto red a zone Alarm or Tam per
event (a LED on or blin king, re spec ti vely), the first line will
show the de scrip tion of the zone con cer ned, as fol lows.
Zone 005
AAADDDDD x ** ÿ
1 2 3 4 5 6 7 8 S T b f s t r i
If the Con trol pa nel has sto red se ve ral zone Alarms
and/or Tam per events in the me mory, the first line will
show the zo nes con cer ned (one-by-one at 3 se cond in -
ter vals). The se cond line will pro vi de in for ma tion on the
sta tus of the Par ti tions. The left-hand side of the di splay
will pro vi de in for ma tion on the sta tus of the Key pad Par -
ti tions, as shown in Table 3.
+
KYO 320 ma na ges 32 Par ti tions. Ho we ver, only 8
Par ti tions can be vie wed on PREMIUM LCD and
CLASSIKA LCD Key pads. The re fo re, the num bers
be low the di splay will cor re spond only when the
first 8 Par ti tions are se lec ted (re fer to Qu ick View
Par ti tion mode).
Tro u ble con di tions will be si gnal led on the right-hand
side of the se cond line. The tro u ble con di tions are re -
pre sen ted by the Icons di rectly be low the di splay. Me -
mory of Tro u ble con di tions will be in di ca ted by an “û“
abo ve the re spec ti ve Icon (re fer to Ta ble 4 for de ta ils).
If the Te le ser vi ce or Answe ring Ma chi ne fa ci lity is Ena -
bled, an aste risk (*) will be shown abo ve the re spec ti ve
Icon (re fer to Ta ble 5 for de ta ils).
If the Te lep ho
ne line is busy or down, a ÿ will ap pe ar
abo ve the Icon (re fer to Ta ble 4 for de ta ils).
nBuz zer
The Key pad so un der will emit a beep each time you
press a key. It will also si gnal:
Ø the Exit time (slow be eps);
Ø the Entry time (fast be eps);
Ø the Auto-arm ti me o ut (four-beep se quen ce);
Ø if the re spec ti ve op tion is ena bled, Par ti tion Alarm or
Tam per event in me mory (two-beep se quen ce);
Ø data in put er rors or in va lid ope ra tions (buzz).
KYO320 OPERATING YOUR SYSTEM FROM A KEYPAD 7
TABLE 2 - ARMING/DISARMING PARTITIONS (LCD KEYPADS)
Initial Mode Result
A
Away
The system will turn ON the perimeter and interior zones of the respective Partition
S
Stay
The system will turn ON the perimeter zones of the respective Partition and will leave
the interior zones OFF.
I
Stay0Delay
The system will turn ON the perimeter zones of the respective Partition and will leave
the interior zones OFF, and will remove the ENTRY TIME from zones which have one.
D
Disarm
The system will turn OFF the perimeter and interior zones of the respective Partition.
-
Disabled
The respectivePartition is not a Keypad Partition, therefore, cannot be controlled from
the keypad.
Note: If the Partition has one or more Alarms in memory the letter will blink.
TABLE3-TROUBLESIGNALS (LCDKEYPADS)
Icon Signalled by Meaning
S
û
ON - Control panel Tamper (Control panel open or dislodged)
Blinking - Control panel Tamper has cleared but at least one Open Panel event in memory
T
û
ON - System Tamper
Blinking - System Tamper has cleared but there is at least one System Tamper event in
memory
b
û
ON - Tamper on at least one peripheral device (Keypad, Reader, Expander or Receiver)
Blinking - Peripheral Tamper has cleared but there is at least one Peripheral Tamper event in
memory
f
û
ON - A False Key/Card is present at a Reader
Blinking - At least one False Key/Card event in memory
s
û
ON - A peripheral device (Keypad, Reader, Wireless or Expander) has been disconnected
Blinking - At least one Peripheral Trouble event in memory
NOTE: To clear the S, T, b and f Trouble signals, select the Reset Alarm option from the User Menu.
