Bentone ST 120 - Working Field ST 120 R;RV; Setting of Brake Plate and Air Flow

9 Bentone
2.4 Setting of brake plate and air flow
a b c
ST 120 R, RV 8,0-9,0 2,7-3,3 0,5-1,5
2.5 Working field ST 120R/RV
1,4-4,3 kg/h
17-51 kW
kW
mbar
Type Motor Complete
burner
Sound
ST 120 R, RV
90W 0,75A 230V
50/60Hz 4µF
230V 0,8A
50Hz
70
dBA ± 0,5
dBA
2.5.1 Electric Specification
Burner correspond to IP 20
a
b
c
-
0,3
0,0
0,3
0,6
0,9
1,2
1,5
1,8
2,1
2,4
15,0 20,0 25,0 30,0 35,0 40,0 45,0 50,0 55,0
!
*NB It is important that
the spark does not strike
against the brake plate or
nozzle
