bentrup TM 100 - Table of Contents

Contents
Front Panel
1
Signal Input A
2 Signal Input B (TM100-x2 / -o2 only)
3 Value Display
4 Select Input A key
5 Select Input B key
6 Max Value Key (value “-” on Inst)
7 Gradient key (value “+” on Inst)
8 on / off key
9
Entering Configuration Key
10
LED to indicate charging (option, as below)
11 Charging socket (rechargable option only)
Introduction .........................................................1
Safety Notes......................................................1
Setup ................................................................1
Displaying Temperatures ......................................2
Maximum Values..............................................2
Absolute Maximums.........................................2
Temperature Gradient .......................................2
Cold Junction Temp. & Battery Voltage .............3
TM100-O2............................................................3
Changing Combustion Composites ...................4
Charging...............................................................4
Replacing Batteries...............................................4
Opening TM100...............................................4
Messages & Display Codes ...................................5
Error Messages..................................................5
Configuration .......................................................6
Parameterlist .....................................................6
Technical Data......................................................7
3
4
6
8
10
1
2
5
7
9
11
BBAA
maxmax
--
gradgrad
++
onon
oo
instinst
charging
