7
No. Description Range Default Unit
7
type of thermocouple 1 - 5 - (S, R, K, J, B)
8 external CJC 0 - 1 0 1 = CJC input B
9 toto 1 - 3 0 (°C, °F, K)
type 1:
Thermocouple
No. Description Range Default Unit
7 typ of resistor 1 1 1 = Pt100
8 wiring type 2 - 3 2 2/3-wire
9 temperature unit 1 - 3 1 (°C, °F, K)
typ 2: Resistor
No. Description Range Default Unit
7 signal type 1 - 6 - 0-20mV, 0-50mV, 0-5V,
(change internal Jumpers accordingly)
0-10V, 0-20mA, 4-20mA
8 value for zeropoint +/- 1999 0 -
9 value for full scale +/- 1999 0 -
Typ 3: Linear
Input
We reserve the right to make any changes without notice
Operating Instructions TM100 V1.0 (c) 2007 bentrup Industriesteuerungen, D-35463 Fernwald
Accuracy 0.1% refered to full scale
Operating temperature range -15 to 55°C
Storage temperature range -25 to 85°C
Batterie lifetime about 2 years (Alkaline)
Batterie lifetime (rechargable) about 6 months (NiMh)
Loading time about 6 hours
Maximum loading cycles >100
Charging power supply 9V AC, 500mA
Technical Data
No. Description Range Default Unit
7 Carbon 0-9,99 3,01 mol amount * 100
8 Hydrogen 0-19,99 8,02 mol amount * 100
9 non combustables 0-9,99 0,01 percent %
Note: For simple calculation of these 3 values an easy to use EXCEL-worksheet can be
downloaded at www.bentrup.de, service, TM100. This allows to calculate the required
data out of the providers gas specifications (percentage of various combustables).
Typ 4: Circone-
Oxide-Probe
