MYNUTE X R
PARAMETERS UM
MYNUTE X R
METHANE GAS (G20) LPG (G31)
Lower Wobbe index (at 15°C-1013 mbar) MJ/m³S 45,67 70,69
Net Caloric Value MJ/m³S 34,02 88
Supply nominal pressure mbar (mm H2O) 20 (203,9) 37 (377,3)
Minimum supply pressure mbar (mm H2O) 10 (102,0) -
20 R
Burner: diameter/length mm 70/86 70/86
Diaphragm: holes number - holes diameter n° - mm 1 - 4,3 1 - 4,3
CH maximum gas capacity
Sm³/h 2,12 -
kg/h - 1,55
DHW maximum gas capacity
Sm³/h 2,12 -
kg/h - 1,55
CH minimum gas capacity
Sm³/h 0,38 -
kg/h - 0,39
DHW minimum gas capacity
Sm³/h 0,38 -
kg/h - 0,39
Number of fan rotations with slow ignition rpm 5.500 5.500
Maximum number of CH fan rotations rpm 6.200 6.000
Maximum number of DHW fan rotations rpm 6.200 6.000
Minimum number of CH/DHW fan rotations rpm 1.600 2.000
Max n° of CH/DHW fan rotations in C(10) conguration (Ø60-100 ● Ø80-125 ● Ø80) rpm 6.200 -
Min n° of CH/DHW fan revolutions in C(10) conguration (Ø60-100 ● Ø80-125 ● Ø80) rpm 1.600 -
30 R
Burner: diameter/length mm 70/125 70/125
Diaphragm: holes number - holes diameter n° - mm 1 - 5,2 1 - 5,2
CH maximum gas capacity
Sm³/h 3,17 -
kg/h - 2,33
DHW maximum gas capacity
Sm³/h 3,66 -
kg/h - 2,69
CH minimum gas capacity
Sm³/h 0,52 -
kg/h - 0,54
DHW minimum gas capacity
Sm³/h 0,52 -
kg/h - 0,54
Number of fan rotations with slow ignition rpm 5.500 5.500
Maximum number of CH fan rotations rpm 6.900 6.900
Maximum number of DHW fan rotations rpm 7.800 7.800
Minimum number of CH/DHW fan rotations rpm 1.700 1.900
Max n° of CH fan rotations in C(10) conguration (Ø60-100 ● Ø80-125 ● Ø80) rpm 6.900 -
Max n° of DHW fan rotations in C(10) conguration (Ø60-100) rpm 8.200 -
Max n° of DHW fan rotations in C(10) conguration (Ø80-125 ● Ø80) rpm 7.800 -
Min n° of CH/DHW fan revolutions in C(10) conguration (Ø60-100) rpm 1.800 -
Min n° of CH/DHW fan revolutions in C(10) conguration (Ø80-125 ● Ø80) rpm 1.700 -
40 R
Burner: diameter/length mm 70/125 70/125
Diaphragm: holes number - holes diameter n° - mm 1 - 5,2 1 - 5,2
CH maximum gas capacity
Sm³/h 3,17 -
kg/h - 2,33
DHW maximum gas capacity
Sm³/h 4,23 -
kg/h - 3,11
CH minimum gas capacity
Sm³/h 0,52 -
kg/h - 0,54
DHW minimum gas capacity
Sm³/h 0,52 -
kg/h - 0,54
Number of fan rotations with slow ignition rpm 5.500 5.500
Maximum number of CH fan rotations rpm 6.900 6.900
Maximum number of DHW fan rotations rpm 9.100 8.900
Minimum number of CH/DHW fan rotations rpm 1.700 1.900
b
DHW functions refer only if a water tank is connected (accessory available on request)
