E-Frame BFR
16
EN
EN
4.2 Charger
The average charge time is 6 hours (at an empty battery).
Charging the battery pack
• The battery charger is only to be used by an adult.
• Check whether the main cord is connected to the charger.
• Connect the charger to the mains voltage. The green indicator lamp will light up.
• Connect the plug to the battery charging point.
• When pushing the o button the LED lights on the battery pack will display the battery charge.
Every green LED represents 25%.
• When the charger shows a green light, the battery pack is fully charged
The battery can only be charged separate from the gokart.
L H
4.3 Display
TURBO
SPEED
TOUR
ECO
Km/h
Km
ODO TRIP AVG DISTANCE TIME POWER CONS
4.3.1 Specications
Type: VLCD-5
Working voltage: DC11V-60V
Max working current: 70mA(11V) 32mA(50V)
Blacklight brightness: 200cd/m²
