BERG E-Frame BFR - Function Description; Operation Procedure

17
E-Frame BFR
EN
4.3.2 Function description
• Speed display
Shows current speed
• Consumption indicator
Six horizontal blocks show the energy level of the battery (each block represents 17% of electric
energy), ickering to remind you to charge the battery.
• Trip distance (resets when the power is o)
Shows trip distance.
• Odograph (ODO)
Shows total distance.
• Average speed (AVG)
Shows average speed.
• Power assist
Show power assist. 4 levels of power assist which adjustable.
• Display backlight
Switch between 2 levels brightness, default is backlight o.
4.3.3 Operation procedure
Button denition
More/higher
Less/lower
Menu
On/o and backlight
Press this button to have power, press this button for 2 seconds to turn o the power.
The system automatically shuts o without any operations for 5 minutes.
/ There are 4 levels of power assist (Eco, Tour, Speed and Turbo). Press these buttons to adjust the
power assist from low to high.
There are 4 mode pages (odometer, trip distance, average speed, one way time). Press this button to
adjust the mode.
Basic functions
• Use the button to switch on the backlight when the power is on
• In the menu at trip distance (TRIP), press the button for 2s to reset the counter and time.
• In the menu at average speed (AVG), shows average speed (average speed=trip distance /
movement time)
• In the menu at movement time (TIME), shows the time of a single trip.
Failure codes
Error Type of error How to solve
ERR-01 Sensor failure Contact your local dealer
ERR-02 Motor hall fault or motor short circuit
Restart using the button
ERR-03 Controller failure Contact your local dealer
ERR-05 Low energy alarm Charge the battery
ERR-06 Cyclist’s feet on the pedal when starting Restart without your feed on the pedal
