Service and Installation Manual
OPERATION
Do not throw items into the storage area. Failure to heed these recommendations could result in
damage to the interior of the cabinet.
REFRIGERATED CYCLE
Refrigerators: During the refrigeration cycle, the evaporator fans will run continuously, will stop when
the door is open to avoid the hot air be sucked into the box.
1.
Every 4 hours, the unit will turn off and to allow the evaporator fin to defrost. The controller now
displays the defrost symbol. When the fin temperature reaches 46°F or after 30 minutes of defrost, the
unit will turn on again.
2.
The factory setting of the temperature range for compressor start and stop is 34° to 41° F.
Freezers: The evaporator fans will run at any time, but will cycle off during a defrost period and when
door is open.
1.
Every 4 hours, the unit will turn off and electric heater will turn on to start the defrost cycle. The
controller now displays the defrost symbol. When the fin temperature reaches 46°F or after 30 minutes
of defrost, the unit will turn on again.
2.
The factory setting of the temperature range for compressor start and stop is -4° to 3°F.
LIGHT
Interior LED light is linked with door switch, when door is open the LED light will be switched on automatically.
REVERSIBLE DOOR
The door is open from left side in production.
Tools needed: Slot type screwdriver, cross screwdriver and hexagon wrench.
Note: locate the cabinet in a level floor and make sure there is enough space for this operation. It’s better to
operate by at least two people.
1. Unscrew the four screws(A~D) with cross screwdriver of the bottom hinge in position 1, then the door can
be removed downward from the cabinet together with the bottom hinge.
