Berner BI4EGV32 - Installation; Electrical data of the units; Function conditions

Page 11 of 44 17.07.2014
Ver. 3.3 © Berner Kochsysteme 2015
Installation
Electrical data of the units
Unit performance (3,5 kW- BIPMS3,5)
Induction unit 1-phase (Voltage 230Volt +5% / -10%)
Connection
colour
Frequency
Fuse
Phase
Brown, Black or 1
50 Hz / 60 Hz
1 x 16A F (super quick)
N
Blue or 2
Working frequency
22-35 kHz
Control fuse
-
PE
Yellow/Green
Unit performance (5 kW- BIPMS5)
Induction unit 2-phases (Voltage 400Volt +5% / -10%)
Connection
colour
Frequency
Fuse
Phase
Brown, Black or 1,2
50 Hz / 60 Hz
1 x 16A F (super quick)
N
Blue or 4
Working frequency
22-35 kHz
Control fuse
-
PE
Yellow/Green
Unit performance (5 kW, 7kW, 8kW, 9kW- BIPS)
Induction unit 3- phases (Voltage 400Volt +5% / -10%)
Connection
colour
Frequency
Fuse
Phase
Brown, Black, Grey or
1, 2, 3
50 Hz / 60 Hz
3 x 16A F
(super quick)
N
Blue or 4
Working frequency
22-35 kHz
Control fuse
-
PE
Yellow/Green
Unit performance (10 kW- BIPDS)
Induction unit 3-phases (Voltage 400Volt +5% / -10%)
Connection
colour
Frequency
Fuse
Phase
Brown, Black, Grey or
1, 2, 3
50 Hz / 60 Hz
3 x 16A F
(super quick)
N
Blue or 4
Working frequency
22-35 kHz
Control fuse
-
PE
Yellow/Green
Unit performance (3,5 kW- BIPDMS3,5) * Model with power star
Induction unit 1-phasig (Voltage 230Volt +5% / -10%)
Connection
colour
Frequency
Fuse
Phase
Brown, Black or 1
50 Hz / 60 Hz
1 x 16A F
(super quick)
N
Blue or 2
Working frequency
22-35 kHz
Control fuse
-
PE
Yellow/Green
Function conditions
o maximum tolerance of the nominal voltage +5%/-10%
o frequency 50 / 60 Hz
o IP CODE (Protection class in delivery state) IP 11
o min. Pan-diameter 12 cm
Installations-environment
- maximum ambient temperature
Storage >-20°C till +70°C in Function >+5°C till +35°C
- maximum relative Atmospheric humidity
Storage > 10% till 90% in Function > 30% till 90%
