Caution:
· Turn power switch to "O" before
threading or unthreading the machine.
· To release the upper thread tension the
presser foot lever has to be raised.
· The thread take-up lever must be in the
highest position when threading.
1. Place spool on pin using appropriate
spool disc (spool turns clockwise). Take
thread through rear guide (A) and then
into slit of upper thread tension.
2. Pull thread down to the right of the
cover around point (B)
3. Take thread up to the left of the cover,
placing it in the take-up lever (C)
4. Take thread down and through guide
(D). Insert the thread through the eye of
the needle from front to back. (needle
threader page 40)
5. Leave about 10 cm (4") of thread loose
behind the needle, or cut the excess
thread by using the thread cutter (E)
Threading the upper threadEN
