Bernette b70 DECO - User Manual

Questions and Answers

D
Donna CobbAug 17, 2025
What to do if my Bernette b70 DECO is skipping stitches?
- R
  Rebecca DavisAug 17, 2025
  If your Bernette sewing machine is skipping stitches, there are several potential causes. Ensure you are using the correct needle system 130/705H. A blunt or bent needle can also cause skipped stitches, so replace the needle. Using a new BERNINA quality needle is also important. Check that the needle is correctly inserted with the flat side to the back, as far up as it will go into the needle holder, and tighten the screw. Finally, make sure the needle point matches the texture of the material you are sewing.
S
Shawn RodriguezAug 20, 2025
Why does my Bernette b70 DECO Sewing Machine have uneven stitches?
- J
  James ThomasAug 20, 2025
  Uneven stitch formation in your Bernette sewing machine can occur for several reasons. It could be due to the upper thread being either too tight or too loose, so try adjusting the upper thread tension. Other potential causes include a blunt or bent needle (replace the needle with a new BERNINA quality needle), poor quality needle (use a new BERNINA quality needle), poor quality thread (use quality thread), an incorrect needle/thread combination (match the needle with the thread size), or the machine being incorrectly threaded (rethread the machine).
P
Patrick WestAug 22, 2025
What to do if the lower thread breaks on my Bernette b70 DECO?
- T
  Travis LeeAug 22, 2025
  If the lower thread is breaking on your Bernette sewing machine, several issues could be the cause. First, check that the bobbin is inserted correctly. Remove and reinsert the bobbin and pull on the thread; it should run easily. Also, verify that the bobbin is threaded correctly. If the stitch hole in the stitch plate is damaged, contact a specialized bernette dealer to have the damages repaired or replace the stitch plate. Finally, a blunt or bent needle can cause thread breakage, so replace the needle.
H
Heather ShawAug 25, 2025
Why does the needle keep breaking on my Bernette b70 DECO Sewing Machine?
- C
  Cheryl CombsAug 26, 2025
  Needle breakage on your Bernette sewing machine can occur if the needle is incorrectly inserted. Ensure you insert the needle with the flat side to the back, as far up as it will go into the needle holder, and tighten the screw. Also, using quality thread can prevent knotted thread, which can cause the needle to break.
J
Juan BeltranAug 28, 2025
Why is the speed too low on my Bernette b70 DECO Sewing Machine?
- F
  fosterjoannAug 28, 2025
  The speed of your Bernette sewing machine might be too low due to unfavorable room temperature; place the machine in a warm room one hour before use. Alternatively, check the settings in the Setup Program and adjust the embroidery speed or the slide accordingly.
L
Laura FosterAug 31, 2025
What to do if the display is inactive on my Bernette b70 DECO?
- B
  Bethany SampsonAug 31, 2025
  If the display on your Bernette sewing machine is inactive, it could be due to incorrect calibrating data. Try switching the machine off, then switch it on while simultaneously pushing the «Center embroidery hoop to the needle/Center embroidery motif» button and keeping it pressed. You might also need to calibrate the display again. If the eco mode is active, touch the «eco» icon again.
M
Melissa ChristensenSep 2, 2025
What to do if my Bernette b70 DECO Sewing Machine doesn't start?
- A
  Andrea CooperSep 2, 2025
  If your Bernette sewing machine doesn't start, it could be due to unfavorable room temperature. Place the machine in a warm room one hour before use. Also, ensure the machine is properly connected and switched on. If the machine is damaged, contact the specialized bernette dealer.
K
Kevin ForbesSep 5, 2025
Why doesn't the «Start-/Stop» button light up on my Bernette Sewing Machine?
- H
  Hayden ScottSep 5, 2025
  If the light on the «Start-/Stop» button of your Bernette sewing machine doesn't light up, it could be due to a defect light, in that case contact the specialized bernette dealer. Alternatively, it might be deactivated in the Setup Program, so activate it there.
C
Christopher RossSep 8, 2025
Why are the sewing light and free arm light not working on my Bernette b70 DECO Sewing Machine?
- M
  Morgan ButlerSep 8, 2025
  If neither the sewing light nor the light on the free arm is lighting up on your Bernette sewing machine, the sewing light could be defective, in that case contact the specialized bernette dealer. Alternatively, check the Setup Program to ensure the lights are activated.
W
Wanda MolinaSep 12, 2025
What to do if there is an error during a software update on my Bernette b70 DECO?
- W
  warrengregorySep 12, 2025
  If you encounter an error during a software update on your Bernette sewing machine and the hourglass on the display is inactive, it indicates the update process is blocked. You can try the following steps: Remove the USB stick, switch the machine off, rename the firmware file from «.fw» to «.auto», insert the USB stick, and then switch the machine on to automatically start the update. If the issue persists, contact the specialized bernette dealer.

Summary

Bernette Embroidery Overview

1.1 Machine Components

Detailed layout and identification of the sewing machine parts.

1.3 User Interface Guide

Explanation of the machine's display, icons, and navigation.

1.5 Key Embroidery Information

Essential tips and details for successful embroidery.

Embroidery Preparation Steps

2.1 Machine Connection & Power On

Steps to connect the machine and switch it on.

2.3 Attaching Embroidery Module

Procedure for connecting the embroidery unit to the machine.

2.4 Embroidery Foot Installation

2.5 Needle Installation Guide

2.6 Threading the Machine

Detailed process for threading both upper and bobbin threads.

2.7 Selecting Embroidery Motifs

2.8 Embroidery Hoop Usage

Machine Setup Program

3.1 Embroidery Settings

Adjusting thread tension, speed, securing stitches, and thread cutting.

3.5 Machine Settings Adjustment

Creative Embroidery Techniques

5.1 Embroidery Process Basics

5.2 Motif Selection and Modification

5.3 Embroidery Time and Size Check

5.5 Editing Embroidery Motifs

Scaling, moving, rotating, mirroring, and deleting motifs.

5.6 Creating Custom Lettering

Adding, editing, bending text, and adjusting stitch density.

5.7 Combining Embroidery Designs

5.8 Changing Thread Colors

Modifying colors and thread brands for motifs.

5.9 Executing Embroidery Motifs

Starting, controlling, and managing the embroidery sequence.

5.10 Managing Embroidery Motifs

Embroidery Process Control

6.1 Embroidering via Start;Stop Button

6.2 Upper Thread Tension Adjustment

BERNINA CutWork Tool Usage

7.1 Changing CutWork Tool

Procedure for replacing the CutWork tool.

7.2 Initiating Cutting Process

Machine Attachment and Maintenance

8.1 Maintenance and Cleaning Guide

8.2 Troubleshooting Common Faults

Solutions for common issues like stitch problems and thread breaks.

8.3 Error Message Explanations

Understanding and resolving machine error messages.

Bernette b70 DECO Specifications

General

Type	-
Interface	USB
Control type	Rotary, Touch
Sewing speed	850
Product color	Black, White
Sewing machine functions	Embroidery
Adjustable thread tension	Yes
Number of illumination LEDs	4
Number of embroidery designs	208
