Bernette b70 DECO - 2.4 Embroidery Foot Installation

Embroidering preparation
24
2019-02 EN 5020070.00A.04
Inserting thread spool
The felt disc prevents the thread from getting hooked at the second spool pin.
> Place the felt disc (1) on the second spool pin.
> Place the thread spool on the second spool pin.
1
2.3 Attaching the Module
NOTICE
Transporting the embroidery module
Damage to the embroidery module connection and machine.
> Remove the embroidery module before transporting the machine.
> Make sure that the module and the machine are placed on a stable, even surface.
> Make sure that there is enough space around to allow the unimpeded movement of the embroidery arm.
> Lift the embroidery module on the left.
> Carefully push the module from left to right into the embroidery module connection (1) of the machine.
1
