Bernette b70 DECO - Overview Front

My bernette Embroidery
10
2019-02 EN 5020070.00A.04
Number Buttons Name Purpose
10 Center the needle
to the embroidery
hoop
> To facilitate threading the needle and to
get enough clearance from the needle to
the hoop, press the icon «Center
embroidery hoop to the needle».
Overview front
2
3
4
6
7
8
9
11
10
1
5
1 Connection for embroidery module 7 Thread cutter
2 Stitch plate cover 8 Slide speed control
3 Stitch plate 9 Thread take-up lever
4 Embroidery foot 10 Top cover
5 Sewing light 11 LCD Display
6 Needle threader
