63
Attaching the module
Attaching the module
Attaching the module
• place the module on the sewing compu-
ter behind the free arm
• push the module from the left towards
the sewing computer so that the connec-
ting lugs engage in the base plate
• Unplug foot control
Releasing the cable
• the cable connects the module to the
sewing computer
• pull the cable out of the holder on the
back of the module
Connecting the cable
• plug with flat side to the front
• insert the plug into the socket on the
right hand side of the sewing computer
Storing the cable on the module
• insert the cable into both cable holders
• press cable gently to secure
Removing the module
• unplug cable
• grip the back right corner to lift the
module and remove to the left
When connecting the em-
broidery module, attention
must be paid that all items
are on a flat and even
surface!
Always separate the module
and sewing computer for
transportation. Never trans-
port them attached.
