Care and maintenance
64
> To remove the brake spring, push a flat object (e.g. screwdriver) under the brake spring until it jumps
out.
> After cleaning, fit the brake spring back into the bobbin case. When doing so, please note the following:
> The brake spring must be inserted into the bobbin case as illustrated below.
– The inner loop of the brake spring (1) must be higher than the outside.
– The opening (2) of the brake spring must face in the same direction as the opening of the bobbin
case.
1
2
> Press both upper tips into the upper openings on the bottom of the bobbin case until they snap into
position.
> Press both lower tips into the lower openings on the bottom of the bobbin case until they snap into
position.
> Check whether the brake spring has been inserted correctly.
– The tips of the brake spring must be visible from outside.
> Place the bobbin into the bobbin case and thread the bobbin thread.
> Insert the bobbin case.
> Close the hook cover.
