Residual heat indication
After the switch off of a heating zone or the complete stop of the hob, the heating zones are still
hot and indicates [ H ] on the display.
The symbol [ H ] disappears when the heating zones may be touched without danger.
As far as the residual heat indicators are on light, don’t touch the heating zones and don’t put any
heat sensitive object on them. There are risks of burn and fire.
Booster and double booster function
Power [ P ] and Super Power [ ] grant a boost of Power to the selected heating zone.
If this function is activated the heating zones work during 10 minutes with an ultra high Power.
This is foreseen for example to heat up rapidly big quantities of water, like nuddles
• Start up / Stop the booster:
Action Control panel Display
Start up the booster Slide to the end of the “SLIDER” [ P ]
Or press directly on the end of
the “SLIDER”
Stop the booster Slide on the “SLIDER“ [ 9 ] to [ 0 ]
• Start up / Stop double booster
Action Control panel Display
Start up the booster Slide to the end of the “SLIDER” [ P ]
Or press directly on the end of
the “SLIDER”
Start up double booster Re-press key [ P ] [ and P ]
Stop the double booster Slide on the “SLIDER“ [ P ] to [ 0 ]
Stop booster Slide on the “SLIDER“ [ 9 ] to [ 0 ]
• Power management:
The table is divided in 3 separate sets of heating zones, each set having a maximum power.
If the selected heating levels for both zones exceed the maximum available amount of power,
the power management function is automatically reducing the power from one of these zones.
The display of this zone is first blinking; the level is then automatically reduced to the highest
suitable position.
Heating zone selected The other heating zone: (example: power level 9)
[ P ] is displayed [ 9 ] goes to [ 8 ] and blinks
It is possible to activate the booster function (or double booster) on several cooking zones at
the same time, for this it is necessary to use the zones in a discriminant way (A-B, A-C, B-C or
A-B-C).
