ELECTRICALCONNECTION
The appliance shall be connected toa single
phase electric line rated at 120/208Vac or
120/240Vacand60Hzfrequency.

Electricpowerrating:
‐120/208Vac:9800Wattor44Amax.
‐120/240Vac:10500Wattor45,5Amax.

Ovenheatingelementspowerrating:
‐Ovenbakeelement=1600Watt
‐Oven
circularelement=2800Watt
‐Ovendoublebroilelement=1200+1800Watt

Inductionheatingelements powerrati ng:
‐
210inductionelement=2300–3700Watt
‐
180 induction element = 1850 – 3000 Watt
(nr.2zones)
‐
145inductionelement=1400–2200Watt

Installasuitableelectricpowersupplyreceptacle
connection type NEMA 14‐50R able to support a
load of at least 40 A (per line)according to local
coderequirements.Forfourorthreewirespower
supplyconnectionsystemseediagrambelow.
FOUR-WIRE CONN.RECEPTACLE NEMA 14-50R
THREE-WIRE CONN.RECEPTACLE NEMA 14-50R


Check your local code for which of the options
belowshould be usedin grounding the
receptaclepowersupplyconnections.
OPTION 1 – FOUR Wires connection:
‐ Connect the L1 receptacle terminal to the
incoming BLACK electrical supply wire (L1‐hot
wire)
‐ Connect the L2 receptacle terminal to the
incoming RED electrical supply wire (L2‐hot
wire)
‐ Connect the NEUTRAL receptacle terminal to
the incoming NEUTRAL (WHITE) electrical
supplywire
‐ Connect the GROUND receptacle terminal to

the incoming GROUND (GREEN) electrical
supplywire
OPTION2‐THREE‐Wiresconnection:
‐ Connect the L1 receptacle terminal to the
incoming BLACK electrical supply wire (L1‐hot
wire)
‐ Connect the L2 receptacle terminal to the
incoming RED electrical supply wire (L2‐hot
wire)
‐ Connect the NEUTRAL with the GROUND 
receptacle
 terminal to the incoming NEUTRAL
(WHITE)electricalsupplywire
DO NOT USE EXTENSION CORDS WITH THIS
APPLIANCEASITMAYRESULTIN FIRE,ELECTRIC
SHOCKOROTHERtypeofPERSONALINJURY.

The appliance isequippe d at the factory with an
electric supply cord set 4 wires type with ring
terminals (L1, L2, N, Ground) suitable for range
use UL/CSA  listed type SRDT/DRT 2x6AWG (L1,
L2)+2x8AWG (N, G) rated 300V,50A with fused
plug type NEMA 14‐50P; cable length 1,5 m.; in

casethesupplycordsetmustbereplaced,itshall
bereplacedwithanidenticalsethavingthesame
technical specs and followingcarefully the
instructionsanddiagramsbelow:
1) Disconnect appliance from electrical power
supplyreceptacle
2) Slideouttheappliancefrominstallationplace
toaccesstobackenclosure
panel
3) Remove back enclosure panel by removing
the6screwsasshownbelow
4) Loose strain relief byunscrewing the two
strainrelief'sscrewsasindiagram.

 
