INSTALLATION INSTRUCTIONS
7
The main consideration when installing any refrigeration unit into a fitted
kitchen is ventilation. The heat removed from the cooling compartment
needs to be dissipated into the atmosphere. Incorrect ventilation can lead to
premature compressor failure, excessive power consumption, total system
failure and may invalidate the warranty provided with the appliance.
For products intended to be installed into a tall housing unit, the following
requirements need to be met:
An air passageway should be
provided in the top of the
cabinet run to allow free air in
and out.
There should be space at the rear of
the cabinet to allow cool air to be
drawn over the condenser.
A cutout should be made in the plinth
below the fridge/freezer and this finished
neatly using the air vent grille.
Alternatively, a thin section of the plinth
can be removed to allow air into the unit,
Size recommended is 2 3 5/8" x 1 37/64"
(600 mm x 40 mm).
