INSTALLATION DIMENSIONS
FRONT VIEW SIDE VIEW
TOP VIEW
Dimensions Size (inches)
Height A 69” 7/8
Width B 35” 7/8
Depth without doors C 24” 3/8
Depth without handles D 29”
Depth with handles E 31” 1/16
Depth with door open 90° F 43” 3/16
Width with door open 90° G 45” 1/16
Depth with door open 122° H 42” 3/16
Width with door open 122° I 60” 5/8
