Berthoud RAPTOR 2540 - Default Chapter; Table of Contents

3
82.490 - Raptor
CONTENTS
1. General and safety __________________________________________________ 5
(See manual No. 82.471)
1.1. Technical specications RAPTOR 2540 - 3240 - 4240 - 5240 6
1.2. Tracks and tyres 9
1.3. Dimensions 13
1.4. Table of weights 14
1.5. Descriptive plates 15
1.6. Position of the safety stickers 16
2. Starting-up the sprayer ____________________________________________ 17
(See manual No. 82.471)
2.1. Rinsing the sprayer before rst use 18
3. Choice of nozzles and tables of ow rates _______________________ 19
(See manual No. 82.467)
4. C-TRONIC regulation _______________________________________________ 19
(See manual No. 82.510)
4.1. Characteristics of the OMEGA pump 20
4.2. Presentation of the C-TRONIC control box 21
4.3. Presentation of the -PILOT multifunction joystick 21
5. Centrifugal pump functions _______________________________________ 23
5.1. Adjustment of the DUALMATIC valves 24
5.2. Filling 25
5.3. Incorporation hopper 26
5.4. Spraying 28
5.5. Transferring 29
5.6. Rinsing operations 30
6. Other sprayer functions ___________________________________________ 35
6.1. Mixing operation 36
6.2. Draining the tank 36
6.3. NIVELEC electric gauge 36
6.4. NIVOMATIC electric gauge (optional) 36
6.5. Handwash tank 36
6.6. Rinsing tank 38
6.7. Rinsing the main tank 38
6.8. Height and slope indexes 38
6.9. Ladder 38
6.10. Height of the boom 38
6.11. External washing device (optional) 40
6.12. External washing procedure 40
