B-6
Wire Feeder Chamber and Spool Cassette
1*
Pre-welding wire speed control knob: Enables change of the wire feed
speed before starting welding process in a range from 1,0 [m/min] to
the value which was set by WFS knob.
2
Burnback Time Knob: Enables to get desired length of electrode wire,
which protrudes from the contact tip of the welding gun after welding
finishing in a range of 20÷320 [msec].
3
Gas Purge Button: Enables shielding gas flow without switching on the
output.
4
Cold Inch Button: Enables wire feeding without switching on the output.
5
Gun Mode Switch: Enables 2-Step or 4-Step gun trigger mode.
6
Wire Feeder System.
7
Cassette for the Spool of Wire.
8
Sleeve for the Spool of Wire: for max 15kg spools. You can use wires
wound onto plastic spools or onto coils which enable loading onto the
sleeve with 51mm diameter. You can also use wires on Readi-Reel®
coils which have to be mounted onto the appropriate adapter.
* Only for PDE 51
