B-22
PDE 51 Wire Drive System
Item Description Part Number Qty
1 Output Motor Gear 0646-231-050R 1
2 Gear Adapter 0646-231-051R 2
3 Incoming Guide Tube 0646-231-109R 1
4 Middle Guide Tube 0646-231-108R 1
5 Paralell Key 0646-231-079R 2
6 Fixing Cap 0646-231-106R 2
7 Pressure Device Assembly 0646-231-082R 1
8 Cover Plate 0646-231-083R 1
9 Roll see accessories 2
10 Right Pressure Arm Assembly 0646-231-105R 1
11 Left Pressure Arm Assembly 0646-231-104R 1
12 Axle Shaft Gear Adaptor 0646-231-048R 2
13 Feed Plate 0646-231-103R 1
14 Pressure Arm Axle 0646-231-107R 2
15 Presure Arm Spring 0646-231-110R 2
Lincoln Electric Bester Sp. z o.o. does not offer any connected parts as spare parts.
For any maintenance or repair operations it is recommended to contact the nearest
Technical Service Center or Lincoln Electric. Maintenance or repairs performed by
unauthorized service centers or personnel will null and void the manufacturer's
warranty.
