Manual Sidedrive Dual Mast Carton Sealer (MSD)
25
Drawings and Parts Lists
ROLLER BED PARTS LIST
BMFAMSD5A
KEY NO. PART NO. QTY DESCRIPTION
1 C4101A03 1 FRAME, ROLLER BED MSD22
2 C4104000 4 LEG, 18” EXTENSION M65X455
3 12554 4 BRACKET, EXTENSION M85X68X6
4 20008 2 SHAFT, T/HEAD M12X155 (BOLTED)
5 C4130010 10 ROLLER, ALUM M48X230
6 C4130030 10 SHAFT, ROLLER M9.5X255 RND/SLT
7 C4129020 32 BUSHING, ROLLER CAP M45X30
8 C4129010 6 ROLLER, ALUM M48X635
9 C4129030 6 SHAFT, ROLLER M9.5X660 RND/SLT
10 C4121001 1 SKID PLATE, FRONT BOTTOM TAPE
11 2712101 4 CASTER, 4” BP (OPTIONAL)
12 2705202 4 WASHER, SPLIT LOCK M6
13 2705203 8 WASHER, SPLIT LOCK M8
14 2705102 4 WASHER, FLAT M6
15 2705101 8 WASHER, FLAT M8
16 2700026 4 SCREW, HEX HD M6X12
17 2701023 8 SCREW, SOCKET HD M8X20
