Manual Sidedrive Dual Mast Carton Sealer (MSD)
27
Drawings and Parts Lists
BELT DRIVE PARTS LIST
BMDBMSD5A
KEY NO. PART NO. QTY DESCRIPTION
1 C4201003 1 PLATE, FIXED BOTTOM LH
2 C4202003 1 PLATE, FIXED BOTTOM RH
3 C4203003 2 PLATE, FIXED TOP LH&RH
4 14021 4 BUSHING, METAL M15X54
5 C4218000 4 SHAFT, IDLE ROLLER M15X60
6 14005 8 SHAFT, PLASTIC WHEEL M15X47
7 14082 2 PULLEY, ALUM FOLLOWER M65.5X50
8 A1122000 2 COUPLER, DRIVE SBLT M35X39
9 C4213001 2 SHAFT, SIDE DRIVE SBT M17X95.5
10 A1224000 4 BRACKET, BEARING 42X42Xt11
11 C4211000 2 PULLEY, ALUM DRIVER SBLT M65.5
12 C4214000 2 PLATE, BELT TENSION (BOTTOM)
13 C4215000 2 PLATE, BELT TENSION (TOP)
14 C4216001 2 BUSHING, FOLLOWER PULLEY M15
15 C4217001 4 SPACER, FOLLOWER PULLEY M21.7
16 14082A 4 PULLEY, ALUM FOLLOWER ASSEMBLY
17 C4211A00 2 PULLEY, ALUM DRIVER ASSEMBLY
18 C4219001 2 SHAFT, BELT TENSION ADJ M12X75
19 C4221000 4 SPROCKET, 15T BELT ADJ M2X15T
20 14006 16 PULLEY, NYLON M65.5X48
21 C4235000 4 PLATE, SUPPORT MOUNT M62X58
22 C4225A03 1 COVER, BELT LH 942L
23 C4226A03 1 COVER, BELT RH 942L
24 C4222000 2 BUSHING, METAL M17.3X54
25 900600SBA 2 BELT, 1850mm X2” BLACK
26 2705102 16 WASHER, FLAT M6
27 2705101 4 WASHER, FLAT M8
28 2705109 4 WASHER, FLAT M8X25X3t
29 2705202 16 WASHER, SPLIT LOCK M6
30 2705203 4 WASHER, SPLIT LOCK M8
