Manual Sidedrive Dual Mast Carton Sealer (MSD)
34
Drawings and Parts Lists
TOP DRIVE PARTS LIST
BMDTMSD5A
KEY NO. PART NO. QTY DESCRIPTION
1 C4401002 1 FRAME, TOP TAPEHEAD MSD22
2 20008 1 SHAFT, T/HEAD M12X155 (BOLTED)
3 20035 1 SHAFT, T/HEAD M12X163 (SPRING)
4 20009 2 SPRING, T/HEAD M10.2X1.2X62.5
5 18029 1 SPACER, STANDOFF HEX H14X29.5
6 53337 1 ROLLER, CHAIN ADJUSTER M26X10
7 C4316000 2 SPACER, MAST SHAFT M30X10
8 18133 2 SPROCKET, RS35X12T
9 C4438000 1 CHAIN, RS35X168 LINK
10 C4441000 1 PLATE, M794X82Xt1.6
11 C4409000 2 PLATE, TOP COMP ROLLERS (L&R)
12 20437 4 SHAFT, COMPRN ROLLER M15X38
13 20024-1 4 WHEEL, TOP COMPR’N GRAY
14 C4411000 2 BRACKET, TOP COMPRESSION KNOB
15 C4409A00 2 COMPRESSION, ROLLER ASSM. MSD
16 C4417000 2 SHAFT, COMP GUIDE M19X287
17 C4413000 1 BRACKET, SLIDE BAR M150X84 (L)
18 C4414000 1 BRACKET, SLIDE BAR M150X84 (R)
19 C4415000 2 PIN, COMPRESSION GUIDE M5
20 C4416000 2 SPRING, LOCK COMPN GUIDE
21 C4317000 1 CAP, FLANGE NYLON M29
22 A1115000 1 HANDLE, STEEL ARM ASSEMBLY
23 2702101 2 KNOB, LOCKING 3/8-13UNC
24 2740205 2 CAP, COMP GUIDE COVER M18X18
25 2706001 1 RING, RETAINING M10
26 2706007 2 RING, RETAINING M14
27 2706004 4 RING, RETAINING M15
28 2706405 2 CLIP, E-TYPE M4
29 2704001 2 SCREW, SOCKET SET M6X6
30 2704002 2 SCREW, SOCKET SET M6X10
