Metallurgical Microscope
Model Number
BS-6000A/AT
User Manual
This manual is written for Metallurgical Microscope of BS-6000A/AT. For safety and for
exerting the best performance, making you familiar with the instrument entirely, it is strongly
recommended that you read this manual carefully before using the microscope.

Table of Contents

Questions and Answers

  • J
    josephpenaAug 18, 2025
    Why is the field of view dark on my BestScope BS-6000A even though the illumination is on?
    • J
      jspencerAug 18, 2025
      If the illumination of your BestScope Microscope is on but the field of view remains dark, it could be due to several reasons. First, check the contact pin and lamp holder pin to ensure they are working well. Second, the lamp bulb may be spoiled, in which case you should replace it with a new one. Third, the brightness adjustment knob might be set too dark, so adjust it to a proper position. Finally, ensure you are using the specified 6V20W halogen lamp.
  • J
    Julia RamirezAug 20, 2025
    How to remove dust and stains from the field of view in BestScope BS-6000A Microscope?
    • A
      Angela IrwinAug 20, 2025
      If you observe dust or stains in the field of view of your BestScope Microscope, the issue might stem from stains present on the specimen itself. In this case, replace the specimen. Alternatively, the eyepiece could be stained, requiring you to clean the eyepiece.
  • R
    Rhonda DavidsonAug 23, 2025
    What to do if the edge of the field of view has a shadow or asymmetrical brightness in BestScope BS-6000A?
    • C
      Craig CraigAug 23, 2025
      If the edge of the field of view has a shadow or the brightness is asymmetrical when using your BestScope Microscope, there are several possible causes. First, ensure that the nosepiece is in the correct, located position. Second, the surface of the lamp may have become black, necessitating a lamp bulb replacement. Third, the filament shadow may not be cleaned up; adjust the condenser knob to change the focus position and clean up the filament shadow. Finally, the lens surface might be moldy or contaminated, requiring you to clean the lens.
  • C
    Courtney DawsonAug 26, 2025
    Why is the image defocus and low-resolution on my BestScope BS-6000A Microscope?
    • K
      Kim WashingtonAug 26, 2025
      If the image appears defocus or has low resolution on your BestScope Microscope, it could be due to several factors. The objective might be damaged, requiring you to mend and correct it by sending it to the factory for overhauling. The lens of the objective and eyepiece may be moldy or have contaminants, so cleaning is necessary. The opening of the aperture diaphragm and field diaphragm might not be proper, causing too much astigmatism, so adjust their openings. The fine focus system could be broken, requiring examination and repair by sending it to the factory for overhauling. Lastly, the objective might not be in the center of the light path, so turn the nosepiece to the located position.
  • M
    Mr. Jacob Gentry MDAug 28, 2025
    What to do if the lamp of my BestScope Microscope won’t light?
    • J
      Jack SteeleAug 28, 2025
      If the lamp of your BestScope Microscope won’t light, first check the power cord and ensure it is connected correctly. Second, verify that the bulb is installed correctly. Finally, the bulb may have burned out, requiring you to replace it with a new one.
  • S
    smithginaAug 30, 2025
    Why is the image focus surface inclined in my BestScope BS-6000A Microscope?
    • J
      Jessica SanchezAug 30, 2025
      If the image focus surface appears inclined, with one side clear and the other faint, on your BestScope Microscope, it could be due to a few reasons. The illumination light might be seriously inclined; adjust the filament position to make the light distribution symmetrical and bright across the field of view. The specimen might not be correctly placed; ensure it is positioned properly. The nosepiece might not be in the located position; turn the nosepiece to the required position.
  • J
    james30Sep 2, 2025
    Why are my eyes uncomfortable when using BestScope BS-6000A and the fields of view don't coincide?
    • A
      Angela HuberSep 2, 2025
      If you experience eye discomfort or the left and right fields of view do not coincide while using your BestScope Microscope, it could be due to a few reasons. The interpupillary distance might not be correct; adjust it accordingly. The diopter might not be right; adjust it according to your sight. You might not be adapted to binocular observation; when looking into the objective, do not stare at the specimen but at the whole field of view, or move your eyes away to see other things, then back into the objective.
  • J
    Jeffery GreenSep 4, 2025
    Why does the bulb burn out frequently in my BestScope Microscope?
    • R
      Riley CarterSep 4, 2025
      If the lamp of your BestScope Microscope is burning out frequently, ensure you are using the required lamp.
  • M
    Megan PalmerSep 7, 2025
    Why is the brightness not sufficient on my BestScope BS-6000A Microscope?
    • J
      Joshua MarshallSep 7, 2025
      If the height of the brightness is not enough on your BestScope Microscope, make sure you are using the appointed lamp. Also, ensure that the brightness adjustment knob is used in a correct way.
  • D
    Dennis ArcherSep 9, 2025
    How to fix a coarse focus knob that is hard to run on BestScope BS-6000A Microscope?
    • J
      jessica55Sep 9, 2025
      If the coarse focus knob on your BestScope Microscope is hard to turn, the tension adjustment collar might be too tight. Loosen it properly.

BestScope BS-6000A Specifications

General IconGeneral
TypeBiological Microscope
Magnification40X-1000X
Optical SystemFinite Optical System
EyepieceWF10X
IlluminationLED
StageDouble Layer Mechanical Stage
Focus MechanismCoaxial Coarse and Fine Focus
NosepieceQuadruple
CondenserAbbe Condenser NA 1.25
LightingLED
Objective Lenses4X, 10X, 40X, 100X
