BestScope International Limited
3
①
②
⑦
2
．
Installation BS-6000A/AT
2.1 Installing Illustration
The following shows the installing order of the spare parts. The number expresses the installing process.
Before the installing, make sure there is no dust and stain on the spare parts. No marks by
outside force on the surface of the spare parts or glass.
Keeping the hexagon- spanner well, when change the spare parts, you will use it.
Body
Objective
Metallurgical
Illumination System
Binocular Viewing Head
10X Eyepiece
③
④
Filter Set
⑤
⑥
Cable W ire
To Next Page
