3. Adjustment & Operation BS-6000A/AT
3.1 Adjustment Set Diagram (Fig.18-19)
Left Fine Focus Knob
Left Coarse Focus Knob
Interpupillary Distance
Diopter Ring
Light Switch
View field Diaphragm
Aperture Diaphragm
Gather Lens Adjust Lever
Fig.18
Tension
Adjustment Collar
