BestScope International Limited
7
BS-6000A/AT
Fig.15
Fig.16
Fig.17
2.2.8 Installing and replacing the lamp
(Fig.14-17)
Please use the specified halogen Lamp 6V30W.
1. Pull out the lamp-house① as the picture show
(Fig.14)
2. Hold to the bulb ①after you wrap it with gauze or
other protection materials, then depress the
plugs② into the jack③ on the lamp house, ensure
the filament and the bolt④ are in a same
level.(Fig.15)
3. Replacing the lamp when using or soon after
When using, or soon after it is turned off, the lamp,
the lamp house and nearby parts will be very hot
and will cause serious burns. Please turn the main
switch on “O” (off), pull up power plug, and make
sure the bulb, the lamp house and periphery are all
cool. Then, you can do your replacing.
Please insert the lamp gently, or it will be
damaged by excessive extrusion.
Do not touch the Halogen bulb with your hands. It
will shorten the service life or cause it to burst. If
you leave fingerprints on the surface carelessly,
clean it with a dry soft cloth.
4. Align the socket① and pins② and align the bolt③
and the jack④. Then push the lamp-house into the
Metallurgical Illumination Set until
covered.(Fig.15-16)
Fig.14
