Beta Marine Beta 35 - Cooling - Fresh Water System, Heat Exchanger

35
HEAT EXCHANGER COOLED

Fresh water circulates through the engine and on to a heat exchanger where it is cooled by sea water which is pumped
through the cooling tubes. The sea water is then injected into the exhaust system (see diagram).
Sea Water Level
41 Heat Exchanger Cooled Engines
