11
Input: balance XLR-3-32 input socket
Input Impedance: 10k
Max input level: +20dBu
Input: balance XLR-3-32 out put socket
Output Impedance: 100
Load impedance: 600
Max input level: +20dBu
Simulation Sound:
Frequency response: 20Hz~20 kHz (+0.3/-0.3dB), 10Hz~30kHz (+0.3/-3.0dB)
Dynamic range: 110dB(A -Weight)
Total distortion and noise : < 0.006%
Min time of delaying: about 1.2ms (we set the delaying parameter of signal input and output as 0)
Others:
Power requirement: AC 220V 50Hz
Power consuming:18W
Dimension(W D H): 482 172 45mm
Weight: 3.0kg
Operation temperature: 0~+40
Storage temperature: -10~+60
Accessories:
Power cable: 1 pcs
The fuse:250mA@220V AC delaying
User manual: 1pcs
Exterior design and specifications are subject to change without notice
9. SPECIFICATIONS
Analog Input:
Analog Output:
A/D Convertor: 48kHz sample frequency, 24bits linear
