EN
5
1. Current clamp
2. Clamp trigger
3. Data hold and backlight
button
4. Mode select button
5. LCD display
6. COM input jack
7. Rotary function switch
8. Range select button
9. Hz/% duty button
10. V- - °C/F jack
11. Battery cover
AC (alternating current) and DC (direct currrent)
Minus sign
4 digits (0 to 3999) measurement reading
Auto Range mode
Diode test mode
Audible Continuity
Data Hold mode
°C, °F, µm,V, A,K, M, - units of measure list
1
2
3
4
5
6
7
8
METER DESCRIPTION
1
2
3
4 5 6 7 8
