EN
12
Insert the Temperature Probe into the negative (COM) and the V jacks, making sure to observe
the correct polarity.
Select C or F with the MODE button.
Touch the Temperature Probe head to the part whose temperature you wish to measure. Keep
the probe touching the part under test until the reading stabilizes (about 30 seconds)
Read the temperature in the display. The digital reading will indicate the proper decimal point
and value.
Warning: to avoid electric shock, be sure the thermocouple has been removed before changing
to another measurement function
Data Hold and Backlight
To freeze the LCD meter reading, press the data hold button. The data hold button is located on
the left side of the meter (top button). While data hold is active, the HOLD display icon appears
on the LCD. Press the data hold button again to return to normal operation.
Note: The HOLD feature will activate when the Backlight is turned on. Press the HOLD key
again to exit Hold.
The backlight function illuminates the display and is used when the ambient light to too low
to permit viewing of the displayed readings.
Press the (HOLD) button for one second to turn the backlight on and press the button
a second time to turn the backlight off.
Manual Ranging
The meter turns on in the autoranging mode. Press the RANGE button to go to manual ranging.
