MAINTENANCE AND CHECKS
BRAKE PUMP OILBRAKE PUMP OIL
BRAKE PUMP OILBRAKE PUMP OIL
BRAKE PUMP OIL
FF
FF
F
ront brakeront brake
ront brakeront brake
ront brake
Check the oil level by means of oiI port-
hole
AA
AA
A. The oil level must be always vis-
ible from the porthole. In contrary case re-
store the oil level.
To restore the oil level, top up by unscrew-
ing the two screws
B,B,
B,B,
B, lifting cap
CC
CC
C and
adding oil.
WW
WW
W
arning:arning:
arning:arning:
arning:
lf you feel the lever too soft, there may be
an air bubble in the circuit. Apply to your
dealer immediately.
Note:Note:
Note:Note:
Note:
For oil changes, follow the instructions
given on the chart on pag. 66, using the
Iubricants recommended on pag. 49.
Rear brakeRear brake
Rear brakeRear brake
Rear brake
Check the level of the brake fl uid through
sightD. The level of the fl uid should never
fall below the mark in the sight.
To restore the level of the brake fl uid,
unscrew cap E and pour in brake fl uid
(BARDAHL BRAKE FLUID DOT 4) until the
level reaches the mark in sight D.
