1
GENERAL INFORMATION
14
GB
DIGITAL RPM INDICATOR
BUTTONS
The instrument is equipped with four buttons which are required for its proper fun-
ctionality (Fig. 2). In their released positions, the buttons’ functions (Up, Down Mode
and Ctrl) are intended as OFF (N.A.).
The buttons’ functionalities are inhibited when the message “SPEED MAX” is shown
on the display.
FUNCTIONAL CHARACTERISTICS
Basic functions
These are the functions which can always be displayed and cannot be de-selected
from the Setup Menu; they also represent the output confi guration with which every in-
strument produced by MAE is programmed. The basic functions include the following:
- Current speed (SPEED); this data is always visible, regardless of whether the vehicle
is stationary or in movement. The default confi guration uses Km/h as the unit of
measure.
- Total distance travelled (ODO); this data can only be displayed by pressing the
mode button, regardless of whether the vehicle is stationary or in movement. The
default confi guration uses Km as the unit of measure.
- Total vehicle operating time measured in hours (H); this data can only be displayed
by pressing the mode button, regardless of whether the vehicle is stationary or in
movement.
