4. Parts Diagram
1 Conductive Silicone Pads 10 Power on / adjust, increase key
2 Integrated Connection Cables 11 CH 1 (Channel 1) Key
3 Belt 12 Power off / adjust, decrease key
4 Hook and loop closure 13 Therapy time remaining
5 CH 1 intensity level 14 Therapy duration status
6 Lock status indicator 15 Program Mode / Therapy time selection
7 Battery status indicator 16 CH 2 (Channel 2) Key
8 CH 2 intensity level 17 Battery compartment
9 Program number 18 Battery cover
Inside
Outside
1
2
34 43
Front Back
5
6
7
8
9
10
11
12
13
14
15
16
17 18
