BFT ALCOR AC A User Manual

INSTALLATION MANUAL
ENGLISH
Terminal
Denition Description
Power
supply
L
LINE
Single-phase power supply
N
NEUTRAL
Motor
10
START + CONDENSER
Motor and condenser connection
11
COM
12
START + CONDENSER
14
START + CONDENSER
Connection between motor and capacitor 2.
Note: if T3=0 do not connect any cable to clamps 14-15-16
15
COM
16
START + CONDENSER
Aux
20
AUX 0 – POWERED CONTACT
230V (N.O.) (40W MAX)
Exit due to FLASHING LIGHT
Contact stays closed while leaves are operating.
21
Accessories
power supply
50
0V-
Accessories power supply output.
51
24V+
52
24 Vsafe+
Tested safety device power supply output (photocell transmitter and safety edge transmitter).
Output act ive only during operating cycle.
Commands
60
Common START and OPEN inputs common
61
START
START command button (N.O.).
Operation according to “Residential / apartment building operation” logic
62
OPEN
OPEN command button (N.O.).
Gate opened with this command. If the input stays closed, the leaves stay open until the
contact is opened.
When the contact is open, the automated device closes following the TCA time, where
activated.
Safety devices
70
Common STOP, PHOT and BAR inputs common
71
STOP
The command stops movement. (N.C.)
If not used, leave jumper inserted.
72
PHOT (*)
PHOTOCELL input (N.C.).
Operation according to “PHOTOCELL/PHOTOCELL DURING CLOSING” logic. If not used, leave
jumper inserted.
73
FAULT 1 Test input for safety devices connected to PHOT.
74
BAR /
BAR CL /
BAR TEST /
BAR CL TEST /
BAR 8K2 /
BAR CL 8K2
(*)
Safety edge input (N.C.).
If not used, leave jumper inserted
BAR/8K2
dip
Safety edge
check
dip
Safety edge
operation
dip
OFF OFF OFF
NC input, no verication, reversal while
opening and closing (BAR)
OFF OFF ON NC input, no verication, reversal only
when closing, stop when opening (BAR
CL)
OFF ON OFF NC input, with verication, reversal
while opening and closing (BAR TEST)
OFF ON ON NC input, with verication, reversal only
when closing, stop when opening (BAR
CL TEST)
ON OFF OFF 8K2 input, reversal when opening and
closing (BAR 8K2)
ON OFF ON 8K2 input, reversal only when closing,
stop when opening (BAR CL 8K2)
75
FAULT 2 Test input for safety devices connected to BAR / BAR CL
Antenna
Y
ANTENNA
Antenna input.
Use an antenna tuned to 433MHz. Use RG58 coax cable to connect the Antenna and Receiver.
Metal bodies close to the antenna can interfere with radio reception. If the transmitter’s
range is limited, move the antenna to a more suitable position.
#
SHIELD
(*) If “D” type devices are installed (as dened by EN12453), connect in unveried mode, foresee mandatory maintenance at least every six months.
(*) In the European Union, apply standard EN 12453 for force limitations, and standard EN 12445 for measuring method.
TABLE “A” - PARAMETERS
Any modication of parameters/logics must be conrmed by pressing S2 > 5s
TRIMMER Parameter
+
min.
+
max.
+
default
Description
T1
Automatic
closing time [s]
0 120 0
Waiting time before automatic closing.
NOTE: Set to 0 if not used.
T2 Work time [s] 5 90 50% Adjusts the motors’ work time, lapsing which they will stop.
T3
Motor 1 closing
delay time [s]
0 25 25%
Motor 1 closing delay time with respect to motor 2.
NOTE: set 0 for single motor operations (leaf 1).
ALCOR AC A -
9
D814011 00100_02
