TABLE “B” - LOGICS
Any modication of parameters/logics must be conrmed by pressing S2 > 5s
DIP Logic Default
Cross out
setting used
Description
1
Transmitter
programming
ON
ON
Enables wireless memorizing of transmitters:
1- Press in sequence the hidden key and normal key (T1-T2-T3-T4) of a transmitter that has already been
memorized in standard mode via the radio menu.
2-
Press within 10 sec. the hidden key and normal key (T1-T2-T3-T4) of a transmitter to be memorized.
The receiver exits programming mode after 10 sec.: you can use this time to enter other new transmitters.
This mode does not require access to the control panel.
IMPORTANT: Enables the automatic addition of new transmitters, clones and replays.
OFF
Disables wireless memorizing of transmitters and automatic addition of clones.
Transmitters are memorized only using the relevant Radio menu or automatically with replays.
IMPORTANT: Disables the automatic addition of new transmitters and clones
2 BAR / 8K2 OFF
ON
Input congured as Bar 8k2 (Fig.G). Input for resistive edge 8K2.
The command reverses movement for 1 sec.
OFF
Input congured as Bar, safety edge (Fig.G).
The command reverses movement for 1 sec..
3
Photocell input
check
OFF
ON Enable safety check on the PHOT input. (Fig.G)
OFF Safety check on PHOT input not enabled. (Fig.G)
4 Edge input check OFF
ON Enable safety check on the BAR input. (Fig.G)
OFF Safety check on BAR input not enabled. (Fig.G)
5
Photocells
during closing
OFF
ON
In the event beam is broken, photocell operation is disabled during opening. During closing, move-
ment is reversed immediately.
OFF
When beam is broken, photocells are active during both opening and clo-
sing. When beam is broken during closing, movement is reversed only once the
photocell is cleared.
6
Safety edge
input operation
OFF
ON Safety edge with active reversal only when closing, when opening the movement stops
OFF Safety edge with active reversal in both directions
7 Fast closing OFF
ON Closes 3 seconds after the photocells are cleared before waiting for the set TCA to elapse.
OFF Logic not enabled
8
Residential /
apartment
building
operation
OFF
ON
Sets the
automation type
of operation:
ON = Apartment building
Reaction to the START input (wired or radio):
Residential Apartment building
CLOSED Opens Opens
WHILE CLOSING Stops Opens
OPEN Closes Closes
WHILE OPENING STOPS + TCA No eect
AFTER STOP Opens Opens
Reaction to the OPEN input (wired):
Residential Apartment building
CLOSED Opens Opens
WHILE CLOSING Opens Opens
OPEN Keep open + TCA Keep open + TCA
WHILE OPENING No eect No eect
AFTER STOP Opens Opens
Reaction to the PEDESTRIAN input (radio):
Residential Apartment building
CLOSED Opens partially Opens partially
WHILE CLOSING Stops Opens partially
OPEN Closes Closes
WHILE OPENING STOPS + TCA No eect
AFTER STOP Opens partially Opens partially
OFF OFF = Residential
9
Hammer during
opening
OFF
ON
Before opening completely, the gate pushes for approx. 2 seconds as it closes. This allows the sole-
noid lock to be released more easily.
IMPORTANT - Do not use this function if suitable mechanical stops are not in place.
OFF
Logic not enabled
10
Stop
maintenance
OFF
ON
If motors stay idle in fully open or fully closed position for more than one hour, they are switched on
in the direction of the stop for approx. 3 seconds. This operation is performed every hour.
NB: In hydraulic motors, this function serves to compensate a possible reduction in the volume of oil
due to a drop in temperature during extended pauses, such as during the night, or due to internal
leakage.
IMPORTANT - Do not use this function if suitable mechanical stops are not in place.
OFF Logic not enabled
