BFT FABER BT - Page 42

Ø 6,5
6
T1
T1
T1
8
25
4
5 6
7
695-700 mm FABER BT
820-825 mm FABER L BT
2
3
1
α°
M8
R1
R1
R1
R2
R2
R2
8
8
FASTENING OF FITTINGS TO LEAF
Unlock the operator as shown and
OPEN the leaf ad far as
required (α°)
Close the leaf and relock
the operator as shown
Fix the bracket following the procedure below:
42 - FABER BT - FABER L BT KIT
D812458 10550_01
