BATTERY REPLACEMENT FUSE REPLACEMENT
MAINTENANCE
A reduction in transmitter range may
be due to the batteries dying� When
the transmitter LED ashes, it means
the batteries are dead and must
be replaced� The battery terminals
should never be short circuited or
touched with your hands�
Remove the batteries and dispose
of them separately according to lo-
cal regulations�
USER GUIDE: MANUAL OPERATION
SWITCH
THE POWER OFF!
SWITCH
THE POWER OFF!
MANUALLY open the gate�
MANUALLY open the gate�
WITH SOLENOID LOCK (OPTIONAL)
WITHOUT SOLENOID LOCK
FABER BT - FABER L BT KIT - 57
D812458 10550_01
