BFT THALIA L - Page 25

INSTALLATION MANUAL
Logic Denition Default
Cross out
setting
used
Optional extras
PRESS SWC
Closing limit switch
pressure
0 
0
Movement is stopped only when the closing limit switch trips: in this case, the tripping of the closing
limit switch must be adjusted accurately (Fig.G Ref.B).
1
Use when there is a mechanical stop in closed position.
This function allows leaves to press against the mechanical stop without the Amperostop sensor
interpreting this as an obstacle.
Thus the rod continues its stroke for a few seconds after meeting the closing limit switch or as far as
the mechanical stop. In this way, the leaves come to rest perfectly against the stop by allowing the
closing limit switches to trip slightly earlier (Fig.G Ref.A).
ICE
Ice feature 0 
0 The Amperostop safety trip threshold stays at the same set value.
1
The controller automatically adjusts the obstacle alarm trip threshold at each start up.
Check that the force of impact measured at the points provided for by standard EN 12445 is lower
than the value laid down by standard EN 12453. If in doubt, use auxiliary safety devices.
This feature is useful when dealing with installations running at low temperatures.
WARNING: once this feature has been activated, you will need to perform an autoset opening and
closing cycle.
1 MOT.ON
1 motor active 0 
0 Both motors active (2 leaves).
1 Only motor 1 active (1 leaf).
OPEN IN OTHER
DIRECT.
Open in other
direction
0 
0 Standard operating mode (See Fig.G Ref. C).
1 Opens in other direction to standard operating mode (See Fig. G Ref.D)
SAFE 1
Conguration of
safety input SAFE 1.
72
0

0 Input congured as Phot (photocell).
1 Input congured as Phot test (tested photocell).
2 Input congured as Phot op (photocell active during opening only).
3 Input congured as Phot op test (tested photocell active during opening only).
SAFE 2
Conguration of
safety input SAFE 2.
74
6
4 Input congured as Phot cl (photocell active during closing only).
5 Input congured as Phot cl test (tested photocell active during closing only).
6 Input congured as Bar, safety edge.
7 Input congured as Bar, tested safety edge.
8 Input congured as Bar 8k2.
SAFE 3
Conguration of
safety input SAFE 3.
77
2

0 Input congured as Phot (photocell).
1 Input congured as Phot test (tested photocell).
SAFE 4
Conguration of
safety input SAFE 4.
79
4
2 Input congured as Phot op (photocell active during opening only).
3 Input congured as Phot op test (tested photocell active during opening only).
SAFE 5
Conguration of
safety input SAFE 4.
79
0
4 Input congured as Phot cl (photocell active during closing only).
5 Input congured as Phot cl test (tested photocell active during closing only).
SAFE 6
Conguration of
safety input SAFE 6.
84
6
6 Input congured as Bar, safety edge.
7 Input congured as Bar, tested safety edge.
IC 1
Conguration of
command input IC 1.
61
0

0 Input congured as Start E.
1 Input congured as Start I.
IC 2
Conguration of
command input IC 2.
62
4
2 Input congured as Open.
3 Input congured as Close.
IC 3
Conguration of
command input IC 3.
64
2
4 Input congured as Ped.
5 Input congured as Timer.
IC 4
Conguration of
command input IC 4.
65
3 6 Input congured as Timer Pedestrian.
