TABLE “A”  PARAMETERS MENU - PARA 
Parameter min. max. Default Personal Denition Description
OPEN DELAY
TI E
0 10 3
Motor 2 opening delay
time [s]
Motor 2 opening delay time with respect to motor 1.
CLS DELAY
TI E
0 25 6
Motor 1 closing delay
time [s]
Motor 1 closing delay time with respect to motor 2.
NOTE: if the time is set to maximum, before starting, engine 1 waits for the complete
shut down of engine 2.
TCA
0 120 10 Automatic closing time [s] Waiting time before automatic closing.
TRF.LGHT.
CLR.T
1 180 40
Time-to-clear trac light
zone [s]
Time-to-clear for the zone run through by trac controlled by the trac light.
OP.DIST.
SLOUD
0 50 10
Slow-down distance during
opening [%]
Slow-down distance for motor(s) during opening, given as a percentage of total travel.
WARNING: Once the parameter has been edited, a complete uninterrupted opening-
closing cycle is required.
WARNING: when the display reads “SET”, obstacle detection is not active.
ATTENTION: with actuators with integrated locks, the permanently active slowdown
to a value higher than 5 is mandatory.
WARNING: in GIUNO, the slow-down distance is set with the sliding sensors
ATTENTION: for the ELI BT A35 engine type, the slowing cannot be excluded; values
below 10% will be considered to be 10%.
CL.DIST.
SLOUD
0 50 10
Slow-down distance during
closing [%]
Slow-down distance for motor(s) during closing, given as a percentage of total travel.
WARNING: Once the parameter has been edited, a complete uninterrupted opening-
closing cycle is required.
WARNING: when the display reads “SET”, obstacle detection is not active.
ATTENTION: with actuators with integrated locks, the permanently active slowdown
to a value higher than 5 is mandatory.
WARNING: in GIUNO, the slow-down distance is set with the sliding sensors
ATTENTION: for the ELI BT A35 engine type, the slowing cannot be excluded; values
below 10% will be considered to be 10%.
DIST.DECEL
0 50 15 Deceleration distance [%]
Deceleration distance (switch from running speed to slow-down speed) for motor(s) both
during opening and during closing, given as a percentage of total travel. WARNING: Once the
parameter has been edited, a complete uninterrupted opening-closing cycle is required.
WARNING: when the display reads “SET”, obstacle detection is not active.
PARTIAL
OPENING
10 99 99 Partial opening M1 [%]
Partial opening distance as a percentage of total opening following activation of PED
pedestrian command.
OP.FORCE
1 99 50
Leaf force during
opening [%]
Force exerted by leaf/leaves during opening. This is the percentage of force delivered,
beyond the force stored during the autoset cycle (and subsequently updated), before an
obstacle alarm is generated.
The parameter is set automatically by the autoset function.
WARNING: It aects impact force directly: make sure that current safety
requirements are met with the set value (*). Install anti-crush safety devices
where necessary (**).
CLS.FORCE
1 99 50
Leaf force during
closing [%]
Force exerted by leaf/leaves during closing. This is the percentage of force delivered,
beyond the force stored during the autoset cycle (and subsequently updated), before an
obstacle alarm is generated.
The parameter is set automatically by the autoset function.
WARNING: It aects impact force directly: make sure that current safety
requirements are met with the set value (*). Install anti-crush safety devices
where necessary (**).
OP SPEED
15 99 99 Opening speed [%}
Percentage of maximum speed that can be reached by motor(s) during opening.
WARNING: Once the parameter has been edited, a complete uninterrupted
opening-closing cycle is required. WARNING: when the display reads "SET", obstacle
detection is not active.
CL SPEED
15 99 99 Closing speed [%]
Percentage of maximum speed that can be reached by motor(s) during closing. WARNING:
Once the parameter has been edited, a complete uninterrupted opening-closing cycle
is required. WARNING: when the display reads "SET", obstacle detection is not active.
SLOW SPEED
15 99 25 Slow-down speed [%]
Opening and closing speed of motor(s) during slow-down stage, given as a percentage of
maximum running speed. WARNING: Once the parameter has been edited, a complete
uninterrupted opening-closing cycle is required. WARNING: When the display reads
“”SET””, obstacle detection is not active.
ATTENTION: for the ELI BT A35 engine type, the slowing cannot be excluded; values
below 50% will be considered to be 50%.
ainte-
nance
0 250 0
Programming number of
operations for maintenance
threshold
[in hundreds]
Allows you to set a number of operations after which the need for maintenance will
be reported on the AUX output congured as Maintenance or Flashing Light and
Maintenance .
(*) In the European Union, apply standard EN 12453 for force limitations, and standard EN 12445 for measuring method.
(**) Impact forces can be reduced by using deformable edges.
