Model (integrated unit) GMV-1565WM/G-X GMV-1623WM/G-X GMV-1679WM/G-X GMV-1734WM/G-X
Model (single unit)
GMV-335WM/G-X+
GMV-615WM/G-X+
GMV-615WM/G-X
GMV-504WM/G-X+
GMV-504WM/G-X+
GMV-615WM/G-X
GMV-504WM/G-X+
GMV-560WM/G-X+
GMV-615WM/G-X
GMV-504WM/G-X+
GMV-615WM/G-X+
GMV-615WM/G-X
Cooling capacity kW 156.5 162.3 167.9 173.4
Heating capacity kW 175.5 182.0 188.5 194.5
Noise dB(A) 68 68 68 68
Outdoor static pressure Pa 0/110 0/110 0/110 0/110
Power
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
Power
comsumption
Cooling kW 7.7+16.2+16.2 12.3+12.3+16.2 12.3+13.8+16.2 12.3+16.2+16.2
Heating kW 7.8+16.9+16.9 12.9+12.9+16.9 12.3+13.1+16.9 12.9+16.9+16.9
Size(W×D×H) mm
930×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690
Waterproof level IPX4 IPX4 IPX4 IPX4
Connection
pipe
Gas pipe mm
Φ
41.3
Φ
41.3
Φ
41.3
Φ
41.3
Liquid pipe mm
Φ
19.05
Φ
19.05
Φ
19.05
Φ
19.05
Connection
method
Welding connection Welding connection Welding connection Welding connection
Net weight kg 220+350+350 295+295+350 295+350+350 295+350+350
Max. power kW 13.02+23.48+23.48 17.36+17.36+23.48 17.36+21.78+23.48 17.36+23.48+23.48
Minimum circuit current A 23.3+42.0+42.0 31.0+31.0+42.0 31.0+38.9+42.0 31.0+42.0+42.0
Max. fuse current A 25+50+50 40+40+50 40+40+50 40+50+50
Model (integrated unit) GMV-1790WM/G-X GMV-1845WM/G-X GMV-1910WM/G-X GMV-1975WM/G-X
Model (single unit)
GMV-560WM/G-X+
GMV-615WM/G-X+
GMV-615WM/G-X
GMV-615WM/G-X+
GMV-615WM/G-X+
GMV-615WM/G-X
GMV-615WM/G-X+
GMV-615WM/G-X+
GMV-680WM/G-X
GMV-615WM/G-X+
GMV-680WM/G-X+
GMV-680WM/G-X
Cooling capacity kW 179.0 184.5 191.0 197.5
Heating capacity kW 201.0 207.0 214.5 222.0
Noise dB(A) 69 69 70 70
Outdoor static pressure Pa 0/110 0/110 0/110 0/110
Power
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
Power
comsumption
Cooling kW 13.8+16.2+16.2 16.2+16.2+16.2 16.2+16.2+20.5 16.2+20.5+20.5
Heating kW 13.1+16.9+16.9 16.9+16.9+16.9 16.9+16.9+20.1 16.9+20.1+20.1
Size(W×D×H) mm
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690
Waterproof level IPX4 IPX4 IPX4 IPX4
Connection
pipe
Gas pipe mm
Φ
41.3
Φ
41.3
Φ
44.5
Φ
44.5
Liquid pipe mm
Φ
19.05
Φ
19.05
Φ
22.2
Φ
22.2
Connection
method
Welding connection Welding connection Welding connection Welding connection
Net weight kg 350+350+350 350+350+350 350+350+355 350+355+355
Max. power kW 21.78+23.48+23.48 23.48+23.48+23.48 23.48+23.48+26.47 23.48+26.47+26.47
Minimum circuit current A 38.9+42.0+42.0 42.0+42.0+42.0 42.0+42.0+47.3 42.0+47.3+47.3
Max. fuse current A 40+50+50 50+50+50 50+50+50 50+50+50
