Model (integrated unit) GMV-2040WM/G-X GMV-2069WM/G-X GMV-2129WM/G-X GMV-2190WM/G-X
Model (single unit)
GMV-680WM/G-X+
GMV-680WM/G-X+
GMV-680WM/G-X
GMV-335WM/G-X+
GMV-504WM/G-X+
GMV-615WM/G-X+
GMV-615WM/G-X
GMV-450WM/G-X+
GMV-504WM/G-X+
GMV-560WM/G-X+
GMV-615WM/G-X
GMV-400WM/G-X+
GMV-560WM/G-X+
GMV-615WM/G-X+
GMV-615WM/G-X
Cooling capacity kW 204.0 206.9 212.9 219.0
Heating capacity kW 229.5 232.0 238.5 246.0
Noise dB(A) 70 71 71 71
Outdoor static pressure Pa 0/110 0/110 0/110 0/110
Power
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
Power
comsumption
Cooling kW 20.5+20.5+20.5
7.7+12.3+
16.2+16.2
10.8+12.3+
13.8+16.2
9.2+13.8+
16.2+16.2
Heating kW 20.1+20.1+20.1
7.8+12.9+
16.9+16.9
10.7+12.9+
13.1+16.9
9.5+13.1+
16.9+16.9
Size(W×D×H) mm
1340×775×1690+
1340×775×1690+
1340×775×1690
930×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
Waterproof level IPX4 IPX4 IP
X4 IPX4
Connection
pipe
Gas pipe mm
Φ
44.5
Φ
44.5
Φ
44.5
Φ
44.5
Liquid pipe mm
Φ
22.2
Φ
22.2
Φ
22.2
Φ
22.2
Connection method Welding connection Welding connection Welding connection Welding connection
Net weight kg 355+355+355 220+295+350+350 290+295+350+350 290+350+350+350
Max. power kW 26.47+26.47+26.47
13.02+17.36+
23.48+23.48
16.89+17.36+
21.78+23.48
15.25+21.78+
23.48+23.48
Minimum circuit current A 47.3+47.3+47.3
23.3+31.0+
42.0+42.0
30.2+31.0+
38.9+42.0
27.3+38.9+
42.0+42.0
Max. fuse current A 50+50+50 25+40+50+50 32+40+40+50 32+40+50+50
Model (integrated unit) GMV-2245WM/G-X GMV-2295WM/G-X GMV-2350WM/G-X GMV-2414WM/G-X
Model (single unit)
GMV-400WM/G-X+
GMV-615WM/G-X+
GMV-615WM/G-X+
GMV-615WM/G-X
GMV-560WM/G-X+
GMV-560WM/G-X+
GMV-560WM/G-X+
GMV-615WM/G-X
GMV-560WM/G-X+
GMV-560WM/G-X+
GMV-615WM/G-X+
GMV-615WM/G-X
GMV-504WM/G-X+
GMV-615WM/G-X+
GMV-615WM/G-X+
GMV-680WM/G-X
Cooling capacity kW 224.5 229.5 235.0 241.4
Heating capacity kW 252.0 258.0 264.0 271.0
Noise dB(A) 71 71 71 72
Outdoor static pressure Pa 0/110 0/110 0/110 0/110
Power
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
Power
comsumption
Cooling kW
9.2+16.2+
16.2+16.2
13.8+13.8+
13.8+16.2
13.8+13.8+
16.2+16.2
12.3+16.2+
16.2+20.5
Heating kW
9.5+16.9+
16.9+16.9
13.1+13.1+
13.1+16.9
13.1+13.1+
16.9+16.9
12.9+16.9+
16.9+20.1
Size(W×D×H) mm
1340×775×1690+134
0×775×1690+1340×
775×1690+1340×775
×1690
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×169
0
Waterproof level IPX4 IPX4 IPX4 IPX4
Connection
pipe
Gas pipe mm
Φ
44.5
Φ
44.5
Φ
44.5
Φ
44.5
Liquid pipe mm
Φ
22.2
Φ
22.2
Φ
22.2
Φ
22.2
Connection
method
Welding connection Welding connection Welding connection Welding connection
Net weight kg 290+350+350+350 350+350+350+350 350+350+350+350 295+350+350+355
Max. power kW
15.25+23.48+
23.48+23.48
21.78+21.78+
21.78+23.48
21.78+21.78+
23.48+23.48
17.36+23.48+
23.48+26.47
Minimum circuit current A
27.3+42.0+
42.0+42.0
38.9+38.9+
38.9+42.0
38.9+38.9+
42.0+42.0
31.0+42.0+
42.0+47.3
Max. fuse current A 32+50+50+50 40+40+40+50 40+40+50+50 40+50+50+50
