Model (integrated unit)
GMV-2470WM/G-X GMV-2525WM/G-X GMV-2590WM/G-X GMV-2655WM/G-X GMV-2720WM/G-X
Model (single unit)
GMV-560WM/G-X+
GMV-615WM/G-X+
GMV-615WM/G-X+
GMV-680WM/G-X
GMV-615WM/G-X+
GMV-615WM/G-X+
GMV-615WM/G-X+
GMV-680WM/G-X
GMV-615WM/G-X+
GMV-615WM/G-X+
GMV-680WM/G-X+
GMV-680WM/G-X
GMV-615WM/G-X+
GMV-680WM/G-X+
GMV-680WM/G-X+
GMV-680WM/G-X
GMV-680WM/G-X+
GMV-680WM/G-X+
GMV-680WM/G-X+
GMV-680WM/G-X
Cooling capacity kW 247.0 252.5 259.0 265.5 272.0
Heating capacity kW 277.5 283.5 291.0 298.5 306.0
Noise dB(A) 72 72 74 74 74
Outdoor static pressure Pa 0/110 0/110 0/110 0/110 0/110
Power
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
380V-415V 3N~
50Hz/60Hz
Power
comsumption
Cooling kW
13.8+16.2+
16.2+20.5
16.2+16.2+
16.2+20.5
16.2+16.2+
20.5+20.5
16.2+20.5+
20.5+20.5
20.5+20.5+
20.5+20.5
Heating kW
13.1+16.9+
16.9+20.1
16.9+16.9+
16.9+20.1
16.9+16.9+
20.1+20.1
16.9+20.1+
20.1+20.1
20.1+20.1+
20.1+20.1
Size(W×D×H) mm
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
Waterproof level IPX4 IPX4 IPX4 IPX4 IPX4
Connection
pipe
Liquid
pipe
mm
Φ
44.5
Φ
44.5
Φ
44.5
Φ
44.5
Φ
44.5
Gas
pipe
mm
Φ
22.2
Φ
22.2
Φ
22.2
Φ
22.2
Φ
22.2
Connection
method
Welding
connection
Welding
connection
Welding
connection
Welding
connection
Welding
connection
Net weight kg
350+350+
350+355
350+350+
350+355
350+350+
355+355
350+355+
355+355
355+355+
355+355
Max. power kW
21.78+23.48+
23.48+26.47
23.48+23.48+
23.48+26.47
23.48+23.48+
26.47+26.47
23.48+26.47+
26.47+26.47
26.47+26.47+
26.47+26.47
Minimum circuit current A
38.9+42.0+
42.0+47.3
42.0+42.0+
42.0+47.3
42.0+42.0+
47.3+47.3
42.0+47.3+
47.3+47.3
47.3+47.3+
47.3+47.3
Max. fuse current A 40+50+50+50 50+50+50+50 50+50+50+50 50+50+50+50 50+50+50+50
NOTES:
a. Rated cooling capacity test conditions: indoor 27°C DB/19°C WB, outdoor 35°C DB; connection pipe
length: 5m, without height drop between units.
b. Rated heating capacity test conditions: indoor 20°C DB, outdoor 7°C DB/6 °C WB; connection pipe
length: 5m, without height drop between units.
c. The total capacity of connected indoor units must be in the range of 50%~135% of the outdoor unit
capacity. The relevant parameters can be corrected by referring to the unit capacity correction table.
d. The above parameters are tested based on the standard connection pipe length. In the actual project,
the parameters should be corrected referring to the capacity correction for the long connection pipe of
units.
