Instruction Manual
BGS technic KG
Bandwirkerstr. 3
D-42929 Wermelskirchen
Tel.: 02196 720480
Fax.: 02196 7204820
mail@bgs-technic.de
www.bgstechnic.com
© BGS technic KG, Copying and further use not allowed
SELF-TEST
If it is working correctly, the condition should be followed:
Red LED should be on when the technician
push the polar switch forward (toward the
positive side).
Green LED should be on when the
technician push the polar switch backward.
(toward the negative side).
.
POLARITY TEST
If its tip is contacting with positive pole, the red
LED will be on.
If its tip is contacting with negative pole, the
green LED will be on.
If its tip is contacting with open circuit, neither
LED will be on
CONDUCTIVITY TEST
By using its tip assisting with ground test lead,
technician can test the conductivity between
wires or components which has been
disconnected from the vehicle electrical system.
If the current is conductible between wires or
components, the green LED should be on.
