SW-Stahl und Werkzeugvertriebs GmbH Tel. +49 (0) 2191 / 46438-0
F 56 essartS resukreveL ax +49 (0) 2191 / 46438-40
ed.lhatsws@ofni :liaM-E diehcsmeR 79824-D
Instruction Manual
BGS technic KG
Bandwirkerstr. 3
D-42929 Wermelskirchen
Tel.: 02196 720480
Fax.: 02196 7204820
mail@bgs-technic.de
www.bgstechnic.com
© BGS technic KG, Copying and further use not allowed
SPECIFICATIONS
Applicable engine type: gasoline engine
2-cycle (1, 2, 3, 4-cylinders)
4-cycle (1, 2, 3, 4, 5, 6, 8, 12-cylinders)
Detection method: ignition spark noise detection
Detection object: High-tension wire or ignition cordially,
CALCULATING THE ROTATIONAL SPEED OF ENGINE
We could calculate the rotational speed of engine according to the measured frequency.
The calculation format is as follows:
N=60 x f x PR
The “n” denotes the rotational speed of engine.
The “f” denotes the frequency of high-tension ignition pulses.
The “PR” denotes the ratio coefficient between the “f” and the “n”.
The number of “PR”, types of engines are as follows:
for four-stroke single-and multi-cylinder engines with distributor: PR = number of cylinders x 2
for two-stroke engine: PR = number of cylinders
WARNING
Do not contact probe tip directly to the secondary ignition circuit!
Do not touch the primary or secondary side of the coil by hand.
Risk of electric shock!
PEAK DETECTION
The operator can pre-select the peak threshold levels, and then contact a circuit if the voltage greater
than the threshold, you can hear the alarm audio.
The peak threshold voltage setting loop incrementally from 0.5 to 1.0, to 2.0 to 5.0, to 10.0, to 48.0
and return back to 0.5 again.
Environmental Protection
Recycle unwanted materials instead of disposing of them as waste. All tools,
accessories and packaging should be sorted, taken to a recycling centre and disposed
of in a manner which is compatible with the environment.
Disposal
Dispose of this product at the end of its working life in compliance with the EU Directive
on Waste Electrical and Electronic Equipment. When the product is no longer required,
it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information or give the product for disposal to BGS technic
or to the dealer where you purchased the product.
