Art. 66525
Axial Joint Tool
SPECFICTION
Applications: assembly and disassembly of axial joints
Joint head Ø: 35 - 45 mm Hollow body: Length 400mm Drive: 27mm outer 6 edge or 1
/2" inner 4 edge
INSTRUCTION
Push the track rod lever is through the hollow body of the
axial joint tool until the head is on top of the axial joint.
Select a 27mm hex socket and set it to the hex at
the end of the hollow body. Solve the axial joint by
turning counterclockwise.
Assemble in reverse order.
NOTE
After installing the new tie rod you must make a wheel alignment.
