Biamp MCA SERIES - Specifications

10
SPECIFICATIONS
SPECIFICATION MCA 8050 MCA 8150
Maximum Power Output (@ 2kHz):
individual channel into 4 ohm load
individual channel into 8 ohm load
bridged channels into 8 ohm load
50 watts/channel
30 watts/channel
100 watts/channel
150 watts/channel
90 watts/channel
300 watts/channel
Signal-to-Noise Ratio (20Hz~20kHz):
at rated power into 4 ohms > 85dB > 85dB
Total Harmonic Distortion + Noise:
20Hz~20kHz @ rated power < 0.2% < 0.2%
Intermodulation Distortion (SMPTE): < 0.35% < 0.35%
Frequency Response (20Hz~20kHz): +0/-1dB +0/-1dB
Input Impedance:
balanced
unbalanced
20k ohms
10k ohms
20k ohms
10k ohms
Input Sensitivity: 0.775 Vrms (0dBu) 0.775 Vrms (0dBu)
Power Requirements: 115/230 VAC, 50/60Hz 115/230 VAC, 50/60Hz
Power Consumption: 900 watts max. 1800 watts max.
Dimensions:
height
width
depth
3.5 inches (89mm) - 2U
19 inches (483mm)
15.5 inches (394mm)
5.25 inches (133mm) - 3U
19 inches (483mm)
15.5 inches (394mm)
Weight: 30 lbs. (13.6kg) 35 lbs. (15.9kg)
Biamp Systems reserves the right to make changes to performance specifications without prior notice.
