MCA Series
TABLE OF CONTENTS
Introduction
Safety Information
Front Panel
Rear Panel
Bridging / Remote Control
Applications
Specifications
Warranty
pg. 1
pg. 2
pg. 3
pgs. 4 & 5
pg. 6
pgs. 7 & 8
pg. 9
INTRODUCTION
MCA Series Multi-Channel Amplifiers provide eight channels of power
amplification. Model MCA 8050 delivers 50 watts/channel into 4 ohms. Model
MCA 8150 delivers 150 watts/channel into 4 ohms. Channels may be bridged
in pairs for higher combined wattage. Connections are provided for remote
control of channel levels & muting. MCA Series amplifiers are covered by
Biamp Systems' five-year warranty.
MCA Series features include:
♦ 8 channels of 50W (MCA 8050) or 150W (MCA 8150)
♦ channels may be bridged in pairs for combined power
♦ terminals for remote control of channel levels/muting
♦ balanced line-level inputs on plug-in barrier strips
♦ rear panel level controls & high-pass filter switches
♦ amplifier outputs on screw-terminal connectors
♦ dual-color signal/peak indicators on front & rear panels
♦ front panel indicators for amplifier temp/load faults
♦ fan cooled with complete output/speaker protection
♦ optional transformers for 25/70/100 Volt systems
♦ incorporates AES recommended grounding practices
♦ CE marked & UL / C-UL listed
♦ covered by BiampSystems' five-year warranty
